Lc 54 Three-doors (36-50 Mm)
Lc 54 Three-doors (36-50 Mm)
Product Codes
Technical Drawing
Assembly Diagram
Lc 54 Three-doors (36-50 Mm)
|
Code
T(mm)
Box
Volume (m³)
Weight (kg)
Weight Birim / Unit
|
|
L-1246
36-50
4
0,009
4,450
Takım
|
| Teknik Çizim / Technical Drawing | Code | T (mt) | Bağ / Band | Volume (m³) | Weight (kg) | Unit |
|---|---|---|---|---|---|---|
|
L-3172-1 | 2.0 | 8 | 0,003 | 1,624 | Adet |
| L-3172-2 | 2.5 | 8 | 0,004 | 2,000 | Adet | |
| L-3172-3 | 3.0 | 8 | 0,004 | 2,200 | Adet | |
|
L-3171-1 | 2.0 | 6 | 0,004 | 0,960 | Adet |
| L-3171-2 | 2.5 | 6 | 0,005 | 1,200 | Adet | |
| L-3171-3 | 3.0 | 6 | 0,006 | 1,200 | Adet |
No technical drawing is available for this product.
Assembly File:
Download PDF
